Machine size: 285*580*900mm
Working format: 300*500/400*400/400*600mm
Cooling method: water cooling
Laser power: 40W-50W
Cutting thickness: 0-10mm(depending on availability)
Drive mode: high speed DSP control
Positioning system: 31 degrees custom board
Computer system: Windows 7/8/9/10
Repeated positioning accuracy: 0.01mm
Minimum formed text: 1*1mm
Maximum engraving speed: 600mm'/s
Maximum cutting speed: 100mm/s
01. LCD control panel
Visual operation panel, graded adjustment,
Accuracy up to 0.1%, easy to adjust
02. Precision laser cutter head
Single and double configuration complete, using flying light
Road design, stable structure, easy adjustment
03. Precision linear guide rail
High speed, high precision, infinite cycle
Long service life, low noise
04. Machine customized motherboard
Support a variety of software direct output
Supports all kinds of vector and bitmap import
05. High precision stepper motor
Stable and safe performance, high torque, low noise
Low heat, accurate operation, longer life
06. Imported laser lenses
It is great in accuracy and service life
Improved, safe and easy to use, strong light transmission
