With the increase of signal switching speed on a PCB, the controlled impedance has been widely used in electronic industry. The importance of controlled impedance in a PCB can depend on various variables, including the particular characteristics and how the circuit board will be used. What’s more, controlled impedance PCB can offer a repeatable high frequency performance in PCB fabrication.
What does impedance mean?
As we all know, impedance is the combination of the inductance and capacitance of an electric circuit at high frequency, and it’s also measured in Ohms. But unlike resistance which is a DC (direct current) characteristic, impedance is an AC (alternating current) characteristic, signifying that it’s related to frequency while resistance is not. When a signal transfers to another identical impedance from the given impedance on a conductor, the transmission is optimum. However, the signal will be worse due to the reflections and attenuation if the impedance is different.
What is impedance control?
Controlled impedance is the characteristic impedance of a transmission line that is made up of PCB conductors. It’s related to high frequency signals that are transmitting on the PCB transmission lines. What’s more, controlled impedance is important for signal integrity because it’s the propagation of signals without distortion.
The PCB impedance is determined by the physical dimensions and PCB materials. It’s measured in Ohms (Ω).
The main factors that affect the impedance of the PCB trances are the width of the copper line, the dielectric constant of the medium, the thickness of the copper line, the thickness of the medium, the thickness of the pad, the traces around the trace, as well as the path of the ground line. At high frequency, PCB trances are not simple connections, controlled impedance can make sure that the signals will work well because they route around a circuit board. Needless to say, controlled impedance PCB can offer a repeatable high frequency performance.
When to use controlled impedance?
It needs to use the controlled impedance when a signal can function properly but needs a particular impedance. In high frequency applications keeping the impedance constant on the electronic PCB is vital to protect the transferred data from damaging and maintain the clarity of the signal. The longer the trace or the higher the frequency, the more adaptation it will need. Also there maybe increase the switching time for an electronic device or circuit and what’s worse, leading to unexpected errors if the impedance of PCB trance connecting two components does not match the characteristic impedance of the components.
Why is controlled impedance so important?
In a printed circuit board or PCB prototype, the aim of a trace is to transfer the maximum signal power from the source to load, however, only the impedance value of the source matches the impedance value of the load can the assignment achieve. Conversely it will reflect the portion of the signal’s energy to the source so that making an effect on the quality. Needless to say, with the quick rise of time signals today, the PCB design with controlled impedance has been widely used in the electronic industry.
Controlled impedance on PCBs
Similarly, with the speed of signal switching on a PCB improves, the electrical properties of the traces carrying signals between devices are more and more important. And the impedance of a PCB trace is controlled by:
· Its configuration
· The dielectric constant of the PCB material
· Dimensions (trace width and thickness as well as the height of the PCB material)
As with a cable, it is easy to reflect the part of the signal and transmit the part when the signal encounters a change of impedance arising from a change in material or geometry. Also, the reflections may lead to aberrations on the signal so that may degrade circuit performance (such as noise, low gain, as well as random errors). In fact, the PCB designers will specify impedance tolerances and values for PCB traces, what’s more, it needs the PCB manufacturer to conform to the specification.
Application of controlled impedance
In general, controlled impedance PCBs are used in fast digital applications as follows:
· Telecommunications
· High quality analog video
· RF communication
· Signal processing
· Computing 100MHz and above
